Project: Tasked with vestibule selection and evaluation, and transferring field notes to an 18×24” unfolded site plan and four evaluations, and an 18×24” oblique plan drawing.

Requirements included:

• Interior footprint not less than 120 square feet and no greater than

  400 square feet

• Minimum of 1 door which stands between exterior and interior

• Minimum of 1 door or threshold which stands between interior and interior

Materials: 2H, HB, 2B Graphite, 18×24” Vellum, 18×24” Trace Paper

Scale: 1/2” = 1”

Right Above: Final Oblique Plan, 45 degrees

Right Below: Final Unfolded Site Plan with Four Elevations
